Tritton IXC™ – ROS-IXC-2SS-T

In Stock

Tritton IXC^™ – ROS-IXC-2SS-T

Tritton IXC^™ Reverse Osmosis Systems

Commercial RO Systems

The Tritton IXC^™ ROS-IXC-2SS-T Commercial Reverse Osmosis System is engineered for higher-capacity commercial applications requiring dependable reverse osmosis performance and consistent product water quality. Its compact vertical configuration utilizes two high-rejection 4″ x 40″ reverse osmosis membranes to provide production capacities ranging from approximately 4,200 to 4,800 gallons per day while maintaining a space-efficient footprint.

The Tritton IXC^™ ROS-IXC-2SS-T Commercial Reverse Osmosis System combines a multistage pump, sediment prefiltration, high-pressure quick connectors, glycerine-filled pressure gauges, and a stainless steel waste and recirculation valve in a durable commercial platform. Its digital control display provides convenient system monitoring with information including product-water TDS, low-pressure status, membrane flush activation, main pump operation, and full-tank indication.

The Tritton IXC^™ ROS-IXC-2SS-T Commercial Reverse Osmosis System is designed for simple operation and convenient maintenance, arriving ready for installation without the need for technician programming. With a 50–60% recovery range, product flow of approximately 2.9–3.2 gpm, and feed flow of 8 gpm, the dual-membrane system is well suited for drinking water, food service, hotel, restaurant, manufacturing, and other commercial applications requiring greater reverse osmosis production capacity.

Applications

✔ Commercial Reverse Osmosis Water Treatment
✔ Higher-Capacity Product Water Production
✔ Commercial Process Water Applications

Recommended Use

✔ Drinking Water Systems
✔ Food Service & Restaurant Operations
✔ Hospitality Water Treatment
✔ Higher-Volume Commercial & Manufacturing Applications

Industries

✔ Restaurants & Food Service
✔ Hospitality (Hotels, Resorts, Lodging)
✔ Commercial Water Treatment
✔ Manufacturing

Specifications

Model: ROS-IXC-2SS-T

Production: 4,200–4,800 GPD

RO Membranes: 2 × 4″ × 40″

Product Flow: 2.9–3.2 GPM

Feed Flow: 8 GPM

Recovery Range: 50–60%

High Pressure Pump Capacity: Maximum 15 GPM

Inlet Connection: 3/4″

Product Outlet Connection: 1/2″

Waste Outlet Connection: 1/2″

System Dimensions: 20″ W × 28″ D × 60″ H

Electrical Power Supply: 220V – 1 PH

Description

The Tritton IXC^™ ROS-IXC-2SS-T Commercial Reverse Osmosis System delivers higher-capacity reverse osmosis treatment with production capacities ranging from approximately 4,200 to 4,800 gallons per day. Its compact vertical design utilizes two 4″ x 40″ high-rejection membranes and commercial-grade components to provide increased water production while maintaining a space-efficient footprint.

Designed for drinking water, food service, hospitality, restaurant, manufacturing, and commercial applications, the ROS-IXC-2SS-T combines simple operation with convenient digital system monitoring and easy maintenance. The system arrives ready for installation with preconfigured controls and provides a 50–60% recovery range with product flow of approximately 2.9–3.2 gpm.

Features & Components

Membrane Housings: Stainless Steel 304 or optional FRP membrane housings.

RO Membranes: Two 4″ × 40″ Hydron high-rejection reverse osmosis membranes.

Pump: Multistage pump designed for dependable commercial operation.

Solenoid Valve: Normally closed 120V brass solenoid valve.

Flow Meter: Panel-mounted flow meter for convenient system monitoring.

Pressure Gauges: 0–100 PSI and 0–300 PSI glycerine-filled pressure gauges.

Waste & Recirculation Valve: Stainless Steel 316 needle valve for system adjustment.

Filter Housing: 20″ filter housing for sediment prefiltration.

Pre-Filtration: 20″ 5-micron polyspun sediment cartridge.

Frame: Standard steel frame with a durable powder-coated finish.

Controller: Aquatrol EC-100 controller with time delay, level switch, Off/Auto operation, optional fast flush, and TDS monitoring of product-water quality.

Safety & Controls: Includes a two-position Off/Auto selector switch, electrical contactor, thermal relay, low-pressure switch, and green LED power indicator.
